qb SoftClaw









qbrobotics has again used the Mechalogic to create a unique gripper. It seems like a traditional claw but smarter and with the intrinsic ability to adapt the applied strength to whatever object it is gripping. A secure and precise grip capable of lifting an iron ball without dropping it or a cream puffs without ruining it, you’ll only need to “tell her” to be strong or soft. Say bye to the long strings of programming, just three words: Soft, Medium, Strong.
qb SoftClaw is a compact, light and versatile Variable Stiffness gripper.
The core of this gripper is the qbmove Advanced, which is an excellent development platform already equipped with motors, electronics and elastic system. On the rear side there’s a mechanical interface compliant to ISO9409-1 and a standard electronic connector to interface with any robotic arm. The mobile finger is driven by the actuator’s shaft, so it can perform a soft movement to grasp objects avoiding damages on critical parts, or a steady grasp by increasing the stiffness; instead, the fixed finger is directly connected to the frame. The gripper can be used by position/stiffness control or by deflection between the equilibrium position and the output shaft. Thanks to this second control, objects of different dimension can be grasped giving the same closure reference (e.g. fully closed) and with the same stiffness for every positions.
Conventional grippers are equipped with a rigid mechanical actuation and can grasp more or less fragile objects only through direct controls on the applied force, therefore using force sensors, or indirect control through the absorbed current. Both of these approaches require specific algorithms and dedicated sensors, which involve limits on the dynamic response times, greater quantity of signals to be managed, higher hardware and software costs. Vice versa, the qb SoftClaw is able to grasp objects of the most disparate nature, exploiting the intrinsic mechanical intelligence of its variable stiffness system, without the use of any type of sensors on the contact surfaces or specific algorithms on the absorbed current by the motors. These aspects make it a versatile, light, economical and very easy to use device.
The gripper offers many development possibilities of geometry and interfaces of fingers; in particular, you can quickly change them with customized finger for your dedicated tasks.
The qb SoftClaw is 100% a plug-and-play device. Thanks to its ease of use and control, it’s very suitable for the following tasks:
- Pick & Place
- Machine tending
- Quality inspection
- Assembly
- Bin Picking
- Testing
- Flexible, Adaptive & Robust
- Plug&Play
- Variable stiffness grasp
- Grasp force: 64N
- Payload: 3.7 kg
- Full closing time: 0.5 s
- Weight: 0,78 kg
- Interchangeable fingers
- Communication protocols: RS485
- ROS Compatible
- UR+ Certified
- ISO/TS 15066
- ISO 9409-1
